Wolverine Tool is a manufacturer of quality toggle clamps and spindles. Every clamp we make uses hardened pins and bushings at all pivot points. We offer a variety of styles and sizes to meet almost every clamping requirement.

CHECK FIXTURE CLAMPS VERSATILE, AND VERY COMPETITIVELY PRICED! Renderings shown with optional arm & spindle
LYT-977-S	LYT-977-SW
A strong and compact clamp for the fixture builder  To learn more, download our data sheet. Please note: Document will open in Adobe Acrobat reader. You will need version 4.0 or higher If you need to update your reader click here.

Our other toggle clamps are available in the following styles:
HOLD DOWN	STRAIGHT LINE	POWER OPERATED	HEAVY DUTY COMPACT

Our standard clamps are built in production quantity to assure off-the-shelf availability and moderate cost to our customers. The careful workmanship and quality materials used in our toggle clamp line will offer you additional economy through better performance and substantially longer service life.

Hold Down Clamps

Our C-100 and C-100-A series are rugged and economically priced with fast action, moderate open clearance. They are designed for general use with holding pressures of 650 - 2050 pounds.

The CQ-1100 and CQ-1100-A series are designed for EXTRA fast, smooth action with maximum open clearance and holding pressures of 600 to 2100 pounds.

For those looking for a clamp that has a narrow profile, visit our CQ-900 series. Available in 9 different models and holding pressures of 750 - 2750 pounds.

Solve interference problems with our Lo-Pro C-300 Series with holding pressures of 600 or 1300 pounds.

---

Straight Line Styles.

Clamps in the C-130 and C-150 series are low profile clamps. They are ideal for locating and clamping with holding pressures of 2500 - 10,000 pounds.

Need a longer stroke? C-133 and C-153 models are accurate, sturdy and budget priced.

Do your parts need to be pulled into position against a locating face? Our C-140 series may resolve your clamping problems.

---

Power Operated

Look no further than our A-1900 Series. Created from the CQ-900 series and available in 3 sizes, these power operated units are readily adaptable to automated or remote controlled clamping systems. Optional magnetic piston and sensing switches now available for fully automatic control.

---

Standard Heavy Duty Compact Clamps.

Available in four sizes with handle and arm extensions offered separately for maximum flexibility in their placement and allowing for the option of providing your own design instead.

Guided Arm Series (available with our no-load lock capability) is ideal for accurate repeatability in clamping or locating.

Latch Open Series  There is an equivalent latch model available for most of our Heavy Duty Compact Clamps.

---

Wolverine Spindles

Maximize your clamping effectiveness by choosing the Wolverine spindle that best fits your clamping application: Standard - Urethane Tip - Datum Pin - Swivel Foot - Spring Loaded

Need something different? Wolverine Tool also designs and builds special clamps to your specifications. We invite you to contact us so we may be of service in helping you solve your clamping problems. With a reputation for quality, personalized service and an eye toward the future since 1926, Wolverine Tool is a name you can trust.
